Cover
Vol. 20 No. 1 (2026)

Published: April 29, 2026

Pages: 14-30

Research Article

Multi-Variable Performance Evaluation of Plastic Concrete for Dam Cut-Off Walls

Shanaz Ahmed 1 Dillshad Khidhir 2
1 Salahaddin University - Erbil
2 Department of Civil Engineering, College of Engineering, Salahaddin University-Erbil, Erbil, Iraq
History
  • Received: August 16, 2025
  • Revised: December 27, 2025
  • Accepted: January 6, 2026
  • Available Online: June 30, 2026
DOI

https://doi.org/10.37650/ijce200102

Abstract

Plastic concrete is widely used in hydraulic cut-off walls of earth and rockfill dams because of its low permeability, high deformability, and good workability. The addition of bentonite clay is also among the primary factors that can influence its performance as it greatly decreases the hydraulic conductivity. Mechanical performance and crack resistance are enhanced by the fiber reinforcement of polypropylene (PP) and steel fibers. This paper investigated the interaction of calcium bentonite dosage, fiber type and content, cement content, and water-to-binder ratio (W/(C +B)) on the flowability, compressive strength, and permeability of 29 plastic concrete mixtures to be used in cut-off wall construction. The experimental tests were performed in accordance with ASTM D6103 on flowability, ASTM C39 on compressive strength and BS EN 12390-8:2019 on permeability. The findings revealed that the best mixtures had a flowability of over 14 cm, compressive strength of 1.23 to 25.78 MPa and permeability coefficients of 10⁻⁹ to 10⁻⁷ cm/s. Adding more bentonite was a very effective way of decreasing permeability, but frequently had adverse effects on compressive strength and workability. Polypropylene fibers showed a more favorable contribution to crack resistance and workability compared to steel fiber. The findings indicate that close fine-tuning of the water to binder ratio (W/(C+B)) as well as dosages of superplasticizer is essential in attaining balanced performance. The study presents a guideline to enhance durable, non-pervious, plastic concrete that can be used in hydraulic works and prepares the groundwork in future investigations of long-term durability and chemical integrity.

Keywords

References

  1. Abbaslou, H., Ghanizadeh, A. R., & Amlashi, A. T. (2016). The compatibility of bentonite/sepiolite plastic concrete cut-off wall material. Construction and Building Materials, 124, 1165-1173.
  2. Akbarpour, A., & Mahdikhani, M. (2023). Effects of natural zeolite and sulfate environment on mechanical properties and permeability of cement–bentonite cutoff wall. European Journal of Environmental and Civil Engineering, 27(3), 1165-1178.
  3. Amritha, E. K., & Paul, N. (2016). Evaluation of the properties of bentonite concrete with and without steel fiber. International Journal of Scientific & Engineering Research, 7(10), 162-166.
  4. American Concrete Institute (ACI). (1999). ACI 229R-99: Guide for use of controlled low strength materials (CLSM). Farmington Hills, MI: ACI.
  5. ASTM C127. (2023). Standard test method for relative density (specific gravity) and absorption of coarse aggregate. American Society for Testing and Materials International, West Conshohocken, PA.
  6. ASTM C128. (2023). Standard test method for relative density (specific gravity) and absorption of fine aggregate. American Society for Testing and Materials International, West Conshohocken, PA.
  7. ASTM C136/C136M. (2023). Standard test method for sieve analysis of fine and coarse aggregates. American Society for Testing and Materials International, West Conshohocken, PA.
  8. ASTM C1602/C1602M (2023). Standard Specification for Mixing Water Used in the Production of Hydraulic Cement Concrete. ASTM International, West Conshohocken, PA.
  9. ASTM C192/C192M. (2023). Standard practice for making and curing concrete test specimens in the laboratory. American Society for Testing and Materials International, West Conshohocken, PA.
  10. ASTM C33/C33M. (2023). Standard specification for concrete aggregates. American Society for Testing and Materials International, West Conshohocken, PA.
  11. ASTM C39/C39M. (2023). Standard test method for compressive strength of cylindrical concrete specimens. American Society for Testing and Materials International, West Conshohocken, PA.
  12. ASTM C511. (2023). Standard specification for mixing rooms, moist cabinets, moist rooms, and water storage tanks used in the testing of hydraulic cements and concretes. American Society for Testing and Materials International, West Conshohocken, PA.
  13. ASTM C617/C617M. (2023). Standard practice for capping cylindrical concrete specimens. American Society for Testing and Materials International, West Conshohocken, PA.
  14. ASTM D6103. (2004). Standard test method for flow consistency of controlled low strength material (CLSM). American Society for Testing and Materials International, West Conshohocken, PA.
  15. Bakhtiari, M. (2021, February 24-27). A Parametric Study on Mechanical Behavior of Plastic Concrete in Cut-off Walls. International Symposium on Water and Dam. [Symposium]. New Delhi, India.
  16. British Standard. (2019). Testing hardened concrete – Part 8: Depth of penetration of water under pressure (BS 12390: Part 8: 2019). British standard Institution.‏ https://www.bsigroup.com/en-GB/.
  17. Di Maio, C. (1996). Exposure of bentonite to salt solution: osmotic and mechanical ffects. Géotechnique, 46(4), 695-707.
  18. Fell, R. (2005). Geotechnical engineering of dams. CRC press.
  19. Gajbhiye, P. K. (2016, November). Construction of deep plastic concrete cut off wall in upstream coffer dam of Punatsangchhu-I Hydropower Project, Bhutan. In Recent Advances in Rock Engineering (RARE 2016) (pp. 353-360). Atlantis Press.
  20. Garvin, S. L., & Hayles, C. S. (1999). The chemical compatibility of cement–bentonite cut-off wall material. Construction and Building Materials, 13(6), 329-341.
  21. ICOLD (2005). Dam Foundations: Geologic Considerations, Investigation Methods, Treatment, Monitoring (Bulletin no. 129). Paris, France: International Commission on Large Dams. https://www.icold-cigb.org/
  22. ICOLD (2018). Cutoffs for dams (Bulletin no. 150). Paris, France: International Commission on Large Dams. https://www.icold-cigb.org/
  23. Jefferis, S. A. (1981, June). Bentonite-cement slurries for hydraulic cut-offs. In Proceedings, Tenth International Conference on Soil Mechanics and Foundation Engineering, Stockholm, Sweden (Vol. 1, pp. 435-440).
  24. Kalaiselvan, R., Madhan kumar, J., & Raghul raj, B. (2018). Experimental Study of Using Bentonite Concrete with and Without Crimbed Steel Fiber in Conventional Concrete. International Journal of Engineering and Technology, 7(3.34), 417-420.
  25. Kazemian, S., & Ghareh, S. (2017). Effects of Cement, Different Bentonite, and Aggregates on Plastic Concrete in Besh-Ghardash Dam, Iran. Journal of Testing and Evaluation, 45(1), 242-248.
  26. Koch, D. (2002). Bentonites as a basic material for technical base liners and site encapsulation cut-off walls. Applied clay science, 21(1-2), 1-11.
  27. Mahboubi, A., & Ajorloo, A. (2005). Experimental study of the mechanical behavior of plastic concrete in triaxial compression. Cement and concrete research, 35(2), 412-419.
  28. Maslak, C. C., Ibuk, H., & Beckhaus, K. (2021, February 24-27). Development of plastic concrete for deep cut-off walls and study on QC testing. ICOLD Symposium on Sustainable Development of Dams and River Basins. [Symposium]. New Delhi, India.
  29. Nateghi, R., Goshtasbi, K., & Nejati, H. R. (2020). Coupled effects of confining pressure and loading rate on the mechanical behavior of plastic concrete. Journal of Materials in Civil Engineering, 32(10), 04020292.
  30. Ostovarzijerdi, A., Ghanbari, A., & Karkon, M. (2019). Investigating the behavior of the plastic concrete made with different types of fibers with an approach to the mixing plans of plastic concrete. Civil Engineering Journal, 5(1), 227-245.
  31. Pashazadeh, A., & Chekaniazar, M. (2011). Estimating an appropriate plastic concrete mixing design for cutoff walls to control leakage under the earth dam. Journal of Basic and Applied Scientific Research, 1(9), 1295-1299.
  32. Pietrangeli, G., Pittalis, G., Rinaldi, M., & Cifra, R. (2019). Design and construction of composite cut-off system at Grand Ethiopian Renaissance Dam, Ethiopia. In Tunnels and Underground Cities. Engineering and Innovation Meet Archaeology, Architecture and Art (pp. 1469-1478). CRC Press.
  33. Pirmohammadi Alishah, F., & Mahmoudzadeh, N. (2020). Investigation of the effect of bentonite paste index on modulus of elasticity, compressive strength and performance of plastic concrete. Civil and Project, 2(5), 87-109.
  34. Rapoport, J., Aldea, C. M., Shah, S. P., Ankenman, B., & Karr, A. (2002). Permeability of cracked steel fiber-reinforced concrete. Journal of materials in civil engineering, 14(4), 355-358.
  35. Razavi, S. K., Hajialilue-Bonab, M., & Pak, A. (2021). Design of a plastic concrete cutoff wall as a remediation plan for an earth-fill dam subjected to an internal erosion. International Journal of Geomechanics, 21(5), 04021061.
  36. Shahidzadeh, M. S., Aliabadi, M. M., Far, H. M., & Nezhad, A. H. D. (2024, November 30). Mechanical and rheological performance of plastic concrete: Investigation of several properties. https://jresm.org/article/resm2024-430me0902rs/
  37. Solanki, L. K., Munzni, B. K., & Vidyarthi, U. S. (2022). Construction of Plastic Concrete Seepage Cut-Off Wall for Polavaram Earth Cum Rockfill Dam. Journal For Research in Applied Science and Engineering Technology, 10(3), 449-458.
  38. Sonebi, M., Hughes, D., Harley, R., & Lynch, K. (2012). Characterisation of the performance of sustainable grout containing bentonite for geotechnical applications. Paper presented at International conference on sustainable built environment for now and the future, Hanoi, Viet Nam.
  39. Valenta, O. (1970). The permeability and durability of concrete in aggressive conditions. In Proceedings 10th International Congress on Large Dams (pp. 103-117).
  40. Yang, Z., Zhang, Y., Zhu, Y., Li, Y., & Fu, R. (2025). The Strength, Permeability, and Microstructure of Cement–Bentonite Cut-Off Walls Enhanced by Polypropylene Fiber. Sustainability, 17(8), 3656.
  41. Zhang, P., Guan, Q., & Li, Q. (2013). Mechanical properties of plastic concrete containing bentonite. Research Journal of Applied Sciences, Engineering and Technology, 5(4), 1317-1322.
  42. Zhou, T., Hu, J., Liu, T., Zhao, F., Yin, Y., & Guo, M. (2023). Engineering Characteristics and Microscopic Mechanism of Soil–Cement–Bentonite (SCB) Cut-Off Wall Backfills with a Fixed Fluidity. Materials, 16(14), 4971.
